11 Setup program
11.4 Configuring the receiver
This chapter explains how to configure a receiver with the setup program. This requires the re-
ceiver and the PC to be connected via an interface.
11.4.1 Establishing communication
There are two different procedures for establishing communication between the receiver and
the setup program:
•
Establish the communication with "device settings assistant"
This is used when the setup program is being used for the first time
(device list is empty).
• Establish the communication without "device settings assistant"
This is used when communication has previously been established between the receiver/
transmitter and the setup program (device list with entries).
Establishing the communication using the assistant
Procedure:
The procedure described above requires communication to be executed on the PC side via a
COM interface (virtual COM interface for USB/TTL).
Step Action
1 Start the setup program.
2 In the "Data transfer" menu, select the "Establish connection" function.
Once the setup program has started, the "device settings assistant" appears.
3 Select the receiver in "Device version" and confirm with "Next".
4 Confirm the PC communication interface "Serial interface" with "Next".
5 Select the COM interface (e.g. COM1) and confirm with "Next".
6 Select the device address (e.g. 1) and confirm with "Next".
7 Exit the assistant with "Finish".
The device list with the selected receiver appears.
8 Click the "Connect" button.
The device list closes, the assistant terminates, and the communication between receiver
and setup program is established.
