ContaminationSensor CS1000 Model code
HYDAC Filtertechnik GmbH en Page 96 / 100
BeWa CS1000 3247149n en 2009-02-04.doc 2009-02-04
Model code
CS 1 0 0 0 - A - 0 - 0 - 0 - 0 /- 000
Product
CS = ContamionationSensor
Series
1 = 1000 Series
Contamination code
2 = ISO4406:1999; SAE AS4059 (D)
3 = ISO4406:1987; NAS 1638
ISO4406:1999; SAE AS4059 (D)
Options
1 = without display
2 = with display, continuously variable rotation by
270°
Fluids
0 = petroleum-based
1 = for phosphate esters
Analog interfaces
A = 4 ... 20 mA
B = 0 ... 10 V
Switching Output
0 = Switch output threshold
Digital interface
0 = RS485
Electrical connection type
0 = plug connection M12x1, 8-pin, pin, according to
VDE0627 or IEC61984
Hydraulic connection type
0 = Pipe or hose connection
1 = Flange connection
Modification number
000 = Standard
