ContaminationSensor CS1000 Overview of menu structure
HYDAC Filtertechnik GmbH en Page 43 / 100
BeWa CS1000 3247149n en 2009-02-04.doc 2009-02-04
Analog output (ANaOUT)
SAE A-D (SAeMAX)
SAE class A/B/C/D (SAE)
SAE class A/B/C/D + Temperature (SAE+T)
Temperature (TEMP)
HDA+ISO (HDaISO)
HDA+SAE (HDaSAE)
ISO-class 4µm (ISO 4)
ISO-class 6µm (ISO 6)
ISO-class 14µm (ISO 14)
ISO Code (ISO)
ISO Code + Temperature (ISO+T)
SAE A (SAE A)
SAE B (SAE B)
SAE C (SAE C)
SAE D (SAE D)
Restart measurement, discard changes (CANCEL)
Restart measurement, save changes (SAVE)
Menu CS 13xx (ISO 4406:1987 and NAS)
Power Up Menu
Measuring mode (MODE)
Mode „1“ (M1)
Mode 2 (M2)
Mode „3“ (M3)
Mode „4“ (M4)
Mode „Single“ (SINGLE)
Measuring time (mTIME)
Set value (60)
Pump protection (pPRTCT)
Set value (0)
Bus address (ADRESS)
HECOM3b address (HECOM)
Set value (A)
(IP) reserved for future use
(MODBUS) reserved for future use
Factory defaults (DFAULT)
Calibration selection (CALIB)
ISO99/SAE (ISoSAE)
ISO87/NAS (ISoNAS)
Cancel (CANCEL)
Save changes, leave Power Up Menu (SAVE)
For internal use (CODE)
Measuring menu
Display (DSPLAY)
ISO-Code (ISO)
NAS-class 2 (NAS 2)
NAS-class 5 (NAS 5)
NAS-class 15 (NAS 15)
NAS-class 25 (NAS 25)
NAS Maximum (NAsMAX)
Flow rate (FLOW)
Analog output (ANaOUT)
Measuring cell LED current (DRIVE)
Temperature (TEMP C)
Temperature (TEMP F)
