ContaminationSensor CS1000 Operating the CS1000 per keyboard (Only CS1x2x)
HYDAC Filtertechnik GmbH en Page 37 / 100
BeWa CS1000 3247149n en 2009-02-04.doc 2009-02-04
ANA.OUT
The measurement category selected here is output at the analog output (see also
section 0)
ANaOUT Select measurement
category for analog
output + Description
SAeMAX SAE A-D
SAE SAE class A/B/C/D (coded)
SAE+T SAE class + temp. (Code)
TEMP Fluid temperature
HDaISO ISO for HDA 5500
HDaSAE SAE for HDA 5500
ISO 4 ISO 4 code
ISO 6 ISO 6 code
ISO 14 ISO 14 code
ISO
ISO 3-digit (Code)
ISO+T ISO 3-digit + temp. (Code)
SAE A SAE class A
SAE B SAE class B
SAE C SAE class C
SAE D SAE class D
