Cs1x1x dimensions (without display), Cs1x2x dimensions (with display) – HYDAC CS 1000 User Manual
Page 17
ContaminationSensor CS1000
CS1000 Features
HYDAC Filtertechnik GmbH
en
Page 17 / 100
BeWa CS1000 3247149n en 2009-02-04.doc
2009-02-04
CS1x1x dimensions (without display)
12
10
6,
5
100
83
ca
. 17
0
25
ISO 228
G1/4
49,2
30
A
B
All dimensions in mm.
CS1x2x dimensions (with display)
ca
. 1
70
10
6,
5
12
102
83
25
ISO 228
G1/4
54,2
30
A
B
All dimensions in mm.
