ContaminationSensor CS1000 Operating the CS1000 per keyboard (Only CS1x2x)
HYDAC Filtertechnik GmbH en Page 41 / 100
BeWa CS1000 3247149n en 2009-02-04.doc 2009-02-04
ANA.OUT
The measurement category selected here is output at the analog output (see
Chapter 0)
ANaOUT Select measurement
category for analog
output + Description
NASMAX NAS maximum
NAS NAS class 2/5/15/25 (coded)
NAS+T NAS class+temp. (coded)
TEMP Fluid temperature
HDaISO ISO for HDA 5500
HDaNAS NAS or SAE for HDA 5500
ISO 2 ISO 2 code
ISO 5 ISO 5 code
ISO 15 ISO 15 code
ISO
ISO 3-digit (coded)
ISO+T ISO 3-digit + temp. (coded)
NAS 2 NAS class 2
NAS 5 NAS class 5
NAS 15 NAS class 15
NAS 25 NAS class 25
