ContaminationSensor CS1000 Using switching output
HYDAC Filtertechnik GmbH en Page 46 / 100
BeWa CS1000 3247149n en 2009-02-04.doc 2009-02-04
Setting limit values
The voltage supply to the CS1000 makes the switching output (SP1) conductive.
This condition is maintained for the initial measurement period (WAIT period).
Depending on the measurement mode, the switching output can be used as a
Device ready function.
Mode 1 (M1) Switching output – OPEN
Switching output –
CONDUCTIVE
- Device ready function
Always CONDUCTIVE except in
the event of an error
Mode 2 (M2) Switching output – OPEN Switching output –
CONDUCTIVE
BEYOND
Above limit
≥ upper limit After switching on or starting a
test.
Becomes conductive again when
all values
≤ respective lower limit
BELOW
Below limit
≤ lower limit value After switching on or starting a
test.
Becomes conductive again when
a value
≥ respective upper limit
WITHIN
Within limit values
Lower limit ≤ measured value ≤
upper limit After switching on or starting a
test.
Becomes conductive again, when
a value < respective lower limit
or
a value > respective upper limit
OUTSDE
Outside limit
values
Measured value ≤ lower limit or
Measured value ≥ upper limit
After switching on or starting a
test.
Becomes conductive again when
the respective lower limit < all
values < respective upper limit
OFF
Off
- Always CONDUCTIVE except in
the event of an error
Mode 2 (M2)
3-digit ISO code
Switching output – OPEN
Switching output –
CONDUCTIVE
BEYOND
Above limit
A value ≥ respective upper limit After switching on or starting a
test.
Becomes conductive again when
all values ≤ respective lower limit
BELOW
Below limit
All values ≤ respective lower limit After switching on or starting a
test.
Becomes conductive again when
a value ≥ respective upper limit
WITHIN Respective lower limit ≤ all values
≤ respective upper limit After switching on or starting a
test.
