ContaminationSensor CS1000 Operating the CS1000 per keyboard (Only CS1x2x)
HYDAC Filtertechnik GmbH en Page 38 / 100
BeWa CS1000 3247149n en 2009-02-04.doc 2009-02-04
Measuring menu (CS13xx)
The Measuring menu allows you to change settings during operation.
Selection To do
Start Measuring menu
Press button
o.k.
.
Exit without saving
Scroll to
CANCEL
and press
o.k.
Or automatically after 30 s without any action
Exit menu and save changes
Scroll to
SAVE
and press
o.k.
Measuring menu: Description
DSPLAY Select display
SWtOUT Set switching output
ANaOUT Select measurement category
for analog output
CANCEL Discard changes and exit
SAVE Save changes and exit
Display — Select displayed measurement category after switching on the sensor
DSPLAY
Select display + Description
ISO 3-digit ISO code
NAS 2 NAS class 2
NAS 5 NAS class 5
NAS 15 NAS class 15
NAS 25 NAS class 25
NASMAX NAS maximum
FLOW Flow rate [in ml/min]
ANaOUT Analog output [in mA]
DRIVE LED current [in %]
TEMP C Fluid temperature in °C
(Celsius)
TEMP F Fluid temperature in °F
(Fahrenheit)
