ContaminationSensor CS1000 Operating the CS1000 per keyboard (Only CS1x2x)
HYDAC Filtertechnik GmbH en Page 39 / 100
BeWa CS1000 3247149n en 2009-02-04.doc 2009-02-04
MODE – Configure measuring mode
Setting the switching output selected in the Power Up menu.
(Only the mode selected in the Power Up menu can be set here.)
SWtOUT Set switching output
o.k.
Description
M1 Continuous measurement
M2 Continuous measurement and
switching
M3 Filter to cleanliness class and
stop
M4 Filter to continuously monitor
cleanliness class
SINGLE Start single measurement +
stop
M1 Continuous
measurement
o.k.
NO SET
M2 Continuous
measurement and
switching
o.k.
+
RELAY1 Test channel
MEAsCH
NASMAX
NAS
ISO 2
ISO 5
ISO 15
ISO
TEMP
NAS 2
NAS 5
NAS 15
NAS 25
SwFNCT Switching
function
OFF
BEYOND
BELOW
WITHIN
OUTSDE
LIMITS Limit values
LOWER
