Remote Viewing
379
8
8.3.4 Alarm Notification
The Single View Viewer can be set to pop up as soon as motion is detected or I/O devices are
triggered. Also up to four captured images will be displayed in the control panel of the Single View. To
enable the function, follow these steps.
Figure 8-21
1. Click
the Show System Menu button (No. 5, Figure 8-19), and select Alarm Notify. This dialog
box appears.
Figure 8-22 Alarm Notification
„ Motion Notify: Once motion is detected, the captured images are displayed in the control
panel of the Single View.
„ I/O Alarm Notify: Once the input device is triggered, the captured images are displayed in the
control panel of the Single View.
„ Alert Sound: Activates the computer noise alarm on motion and input-triggered detection.
„ IE Window Pops Up: The minimized Single View pops up on motion and input-triggered
detection.
„ Auto Snapshot: The program will take a snapshot every 5 seconds on motion and
input-triggered detection.
„ File Path: Assigns a path to save the snapshots.
2. Click OK to apply the above settings.
3. Minimize your browser to test the pop-up function.
Captured images Pop-up live video
