Video Analysis
153
3
3.3 Digital Object Tracking
Without the need of a PTZ camera, the Digital Object Tracking provides you real-time tracking of up to
7 moving objects and automatic magnification of the targeted objects. The digital tracking function
which combines with PIP View or PAP View can be an aid to spot any suspicious activities under the
surveillance area.
Note: An AVP dongle is required for the function to work.
3.3.1 Setting Digital Object Tracking
1. Click the Configure button (No. 14, Figure 1-2), click Advanced Video Analysis, and select
Digital Object Tracking Setting.
2. Select the camera to be configured and click the Configure button. This dialog box appears.
Figure 3-14
3. Select a camera from the Camera Selection drop-down list.
4. In the Definition section, there are three options:
„ Mask Region: Use the mouse to outline a mask area where motion will be ignored.
„ Min Object Size: First click the button to pause live images and then use the mouse
to outline the minimum object size for tracking on the image.
„ Max Number of Tracked Objects: Use the slider to choose the maximum number of
objects to be tracked. The maximum value is 7. This number also determines how many
