Configuring Main System
101
1
1.17 Fisheye View
A fisheye camera allows you to cover all angles of a location with just one fisheye camera. The
distorted hemispherical image produced by the fisheye camera will be converted to a conventional
rectilinear projection.
The following cameras are supported:
•
GV-FE110 fisheye camera
• Install an ImmerVision IMV1 Panorama Lens on any camera without a built-in lens
• Install a third-party fisheye lens on the GV-IPCAM H.264 Camera of Box module
• Install a third-party fisheye lens on any IP camera supported by GeoVision
To monitor the entire room, mount the camera on the ceiling with the fisheye lens pointing downward.
You can choose among four view modes and adjust the PTZ views to different angles.
Quad view: 4 PTZ views 360 degree: 2 PTZ view & 1 360º view
Dual 180 degree: 2 180º views Single view: 1 PTZ view
Figure 1-82
