138
Application Example
A resolution of 640 x 480 has been selected for the On Demand Display function.
•
Higher Resolution Streaming
Figure 2-14
The camera image in the middle has a resolution of 1152 x 648, so the higher resolution streaming
will be used, because 1152 x 648 is bigger than the selected 640 x 480.
•
Lower Resolution Streaming
Figure 2-15
After switching to 16-channel screen division, the resolution for each channel is 480 x 270, which is
smaller than the selected 640 x 480, so the lower resolution streaming will be used.
Note:
1. The
On Demand Display function is not supported for Privacy Mask, Defog and Stabilizer.
2.
If the same resolution has been set for both video streams, the On Demand Display option
will still be visible, but automatic resolution adjustment will not occur.
