Playing Back Video Files 4
4.4 Quick Search
Quick Search is a very useful tool for searching and playing back POS events. In Advanced Log
Browser (Figure 4-30), double-click any POS event in the POS table. The Quick Search window will
appear. The following figure and table give you an overview on Quick Search’s features and functional
buttons.
Note: If the Quick Search window doesn’t appear, click the Configure button (No. 14, Figure 1-2) on
the Main System, select General Setting and select System Log Setting. Then in the POS Table
drop-down list, change the video player from ViewLog to Quick Search.
1
3
4
5
6
2
7
8
9 12 10 13 14 15 11
Figure 4-33 Quick Search
The controls on the Quick Search window:
No. Name Description
1 Monitoring Window
Displays video associated to the event. Right-click on the window to have
the options of Play Mode, Render and Tools.
2 Camera Select Use the drop-down list to select camera
3 Day Select Use the drop-down list to select date
4 Time Select Use the drop-down list to select time
5 Go Button Click to search files that match to the parameters set above.
6 Event Query
Click to specify event query. See Event Query Settings later in this
chatper.
7 Transaction Use the arrow buttons to select previous or next transaction event.
8 Void Use the arrow buttons to select previous or next void event.
247
