Hybrid and NVR Solution
135
2
5. Under
the
Economic Frame Rate Setting section, configure the frame rate settings for the
incoming IP video compressed with JPEG, MPEG or H264 codec.
z
To configure the frame rate setting for the IP video compressed with JPEG:
A. Select
JPEG.
B.
Specify the number of frame rates per second for different situations: when motion is
detected (the Max. Recording Frame Rate of Motion option), when I/O devices are
triggered (the Max. Recording Frame Rate of I/O Trigger option), when no motion is
detected or when no I/O devices are triggered (the Max. Recording Frame Rate of
Non-Motion or Non-I/O Trigger option).
z
To configure the frame rate setting for the IP video compressed with MPEG or H.264:
A. Select
MPEG_H264.
B.
Select to record in the maximum frame rate or record key frames only for different
situations: when motion is detected (the Max. Recording Frame Rate of Motion
option), when I/O devices are triggered (the Max. Recording Frame Rate of I/O
Trigger option), when no motion is detected or when no I/O devices are triggered (the
Max. Recording Frame Rate of Non-Motion or Non-I/O Trigger option).
6. Under
the
Motion and I/O Trigger Setting section, select one of the following options to specify
the conditions to begin recording according to the Economic Frame Rate Setting you set in Step 5.
Motion and I/O (Motion First): The video images will be recorded according to your
selection under the Economic Frame Rate Setting section when motion is detected or
when the I/O device is triggered. However, when both motion detection and I/O trigger
occur at the same time, the frame rate setting of motion detection will override the frame
rate setting of I/O trigger.
Motion and I/O (I/O First): The video images will be recorded according to your selection
under the Economic Frame Rate Setting section when motion is detected or when I/O
devices are triggered. However, when both motion detection and I/O trigger occur at the
same time, the frame rate setting of I/O trigger will override the frame rate setting of motion
detection.
Motion Only: When motion is detected, the video images will be recorded according to
your selection in Max. Recording Frame Rate of Motion.
I/O Only: When I/O devices are triggered, the video images will be recorded according to
your selection in Max. Recording Frame Rate of I/O Trigger.
7. Click
OK to apply the settings and select Start All Monitoring to run the application.
