482 C HAPTER 19: M ANAGING C ABLE M ODEMS
IP Protocol Indicates the value of the IP protocol field necessary
for IP packets to match this rule.
A value of 256 matches traffic with any IP protocol
value. A value of 257 matches both TCP and UDP. If
the referenced parameter is not present in the
classifier, the value is 258.
IP Src Addr Indicates the value of the IP source address necessary
for packets to match this rule.
IP Src Mask Specifies the bits of a packet’s IP source address to
compare when matching this rule.
IP Dest Addr Specifies the low end inclusive range of TCP/UDP
source port numbers to which the packet compares.
This parameter is ignored for non-TCP/UDP IP packets.
If the referenced parameter is not present in the
classifier, the value is zero.
IP Dest Mask Specifies the bits of a packet’s IP destination address
to compare when matching this rule.
IP Src Port Start Specifies the low and inclusive range of TCP/UDP
source port numbers to which a packet compares.
IP Src Port End Specifies the high end inclusive range of TCP/UDP
source port numbers to which a packet compares.
IP Dest Port Start Specifies the low end inclusive range of TCP/UDP
destination port number to which a packet compares.
Parameter Description
