Cuda 12000 IP Access Switch CLI-based Administration Guide
Defining Modulation Profiles 421
FEC-tbytes
The Fec-tbytes parameter is the number of errored bytes that can be
corrected in forward error correction code. By default, FEC-tbypes is set at
zero. The value of zero indicates no correction is employed. Acceptable
values are 0 to 10. The number of check bytes appended will be twice the
value that is set.
You set the FEC-tbypes by performing the following tasks:
.
3. Disable the differential
encoding.
modulation-profile
interval-usage {initial | long | request | short |
station} no-diff
Task Command
1. Enter cable interface
mode.
interface cable
Configure FEC error
correction. modulation-profile
interval-usage {initial | long | request | short |
station} fec-tbytes <0..10>
Task Command
