396 C HAPTER 18: C ONFIGURING C ABLE M ODEM T ERMINATION S YSTEMS
Modulation Profile
The Profile Index number that identifies the properties of the Upstream
Channel ID.
You assign a modulation profile to an upstream channel by performing the
following tasks.
Data-Backoff
The data-backoff parameter sets a fixed start value for initial data backoff on
the upstream channels. By default, the TX data backoff Start parameter is set
to 5. Acceptable values are 0 to 15.
You set the data backoff range on the upstream channel by performing the
following task.
Task Command
1. Enter interface cable mode. interface cable
2. Specify the modulation profile
that you want the channel to
utilize.
upstream
modulation-profile <profile
number>
Task Command
1. Enter interface cable mode. interface cable
2. Configure the transmit backoff
range.
upstream
data-backoff
