Cuda 12000 IP Access Switch CLI-based Administration Guide
Configuring Upstream Channels 399
7. Set the upstream channel
frequency. Valid range: 5.0
– 42.0 MHz.
upstream frequency
8. Set the mini-slot size for the
downstream channel.
upstream minislot-size
{2 | 4 | 8 | 16 | 32 | 64 | 128}
9. Set the receive power level.
Acceptable range: -160 –
260 TenthdBmV.
upstream power-level
10.Set the upstream channel
width.
upstream channel-width
{200 | 400 | 800 | 1600 | 3200}
11.Specify the modulation
profile. Acceptable profile
numbers:1 – 2.
upstream modulation-profile
12. Verify the upstream
configuration for the
selected channel.
show interface cable <c/s/i> upstream [number>]
Task Command
