Horner APG XL4 OCS - Manual (Page 9)

MAN0964-01-EN Visual Map
June 29, 2012 Page 9 of 122
Visual Map of major tasks and the key chapters to assist you
FIRST STEP of ANY TASK: DATASHEET
Each XL4 OCS unit is sent with a datasheet in the box. The datasheet is the first document you
need to refer to for model-specific information related to XL4 OCS models such as pin-outs,
jumper settings, and other key installation information. Visit our website
http://www.heapg.com to
obtain updates to datasheets, manuals and user documentation.
QUICK START INSTALLATION PROGRAMMING TROUBLESHOOTING
Safety / Compliance
page 11
Safety / Compliance
page 11
Safety / Compliance
page 11
Safety / Compliance
page 11
Introduction
page 13
Introduction
page 13
Introduction
page 13
Introduction
page 13
Mechanical Installation
page 17
Serial Communications
Page 25
Maintenance
page 113
Electrical Installation
page 23
CAN Communications
page 27
Troubleshooting
page 115
Ethernet
Page 29
Communication Options
page 35
Removable Media
page 37
High Speed I/O
page 49
System Settings
page 59
User Interface
page 73
Registers
page 83
Cscape Configuration
page 89
Fail- Safe System
Page 101
Clone Unit
Page 109
