CH.2 MAN0964-01-EN
June 29, 2012 Page 14 of 122 #1037
2.1.2 Four main types of information are covered in the manual.
a. Safety and Installation guidelines / instructions (Mechanical and Electrical)
b. Descriptions of hardware features
(Serial ports, Removable Media, Communication Options, etc.)
c. Configuration and Use of the XL4 OCS
d. Maintenance and Support
2.1.3 Manual Index
Index
Major topics of interest may be found in the Index towards the end of this manual.
2.1.4 Table of Figures
Table of Figures
Location of important drawing, illustrations (etc) may be found in the Table of Figures .
2.2
Connectivity to the XL4 OCS
The XL4 OCS has excellent capabilities for connecting to a variety of devices. The diagram below shows
some examples of devices that can be used with the XL4 OCS.
Figure 2.3 – Visual Overview of Types of Devices that can be connected to XL4 OCS
2.3
Features of XL4 OCS
The XL4 OCS are all-in-one industrial control devices. They combine control, user interface, I/O and
networking into a single, integrated package. Unique features of the XL4 OCS include:
• Bright, 65536 color graphical touch sensing LCD display in all models of XL4.
• Display of complex graphical objects including trends, gauges, meters and animations.
• Very high performance graphic processing
• Advanced control capabilities including floating point, multiple auto-tuning PID loops and string
handling capabilities.
CAN Serial
I/O
XL4 OCS
Other OCS Devices
Drives
PLCs
Bar Code Readers
Printers
SCADA
OPC Servers
Serial I/O
Sensors
Indicators
Alarms
Encoders
Pumps
Relays
Solenoids
Other OCS Devices
Smart Stix I/O
RCX116 I/O Base
OPC Server
Ethernet
Cscape
OPC Server
Modbus TCP Devices
USB
Flash Drive
Cscape
