MAN0964-01-EN CH.7
June 29, 2012 Page 33 of 122 #1037
For the Status and Version registers (if configured), the Direction settings are always Read Only.
The Use CAN ID for last Octet checkbox does not affect Net Mask, Gateway, Status or Version
configuration.
Ethernet Module Protocol Configuration
The Protocol Support area contains a list of all the protocols supported by the platform being
configured. To activate a protocol, check its checkbox.
For protocols that require additional configuration, click on a listed protocol to select it and then click
the Configure Selected Protocol button. This will open a new dialog with configuration options for the
selected protocol.
For detailed information on individual protocol configuration refer latest version of ETN 300 Manual
SUP0740
