MAN0964-01-EN CH.10
June 29, 2012 Page 47 of 122
The analog inputs have a digital filter that can be used to filter electrical noise that may be unavoidable in
some installations. The downside to digital filtering is the inputs will respond more slowly to sudden
changes in the actual input.
10.8
Universal Analog Inputs
Note: See the data sheet for the XL4 OCS model you are using for jumper settings and see the
appropriate pages in this manual (see
Index ) for details on how to use Cscape to configure the digital
filtering.
The universal analog inputs provide a high resolution, very flexible interface for a variety of analog inputs.
These inputs include voltage, current, thermocouple, RTD and millivolt. Each channel can be configured
separately using jumpers and configuration settings in Cscape.
Like the standard analog inputs, these inputs have a digital filter that can be used to filter electrical noise
that may be unavoidable in some installations. The downside to digital filtering is the inputs will respond
more slowly to sudden changes in the actual input.
10.9
Analog Outputs
Note: Refer to the datasheet for XL4 OCS model you are using for details on jumper settings.
The analog outputs on XL4 OCS devices provide high resolution voltage or current outputs. The voltage
or current selection is controlled with jumpers and configuration settings in Cscape. Note that each
channel can be separately configured for voltage or current mode.
When the controller is stopped the operation of each output is configurable. The outputs can hold the
state they were in before the controller stopped or they can go to a predetermined value. By default
analog outputs are set to a value of zero. For more information on Stop State, refer to the appropriate
pages (see
Index ) for the configuration chapter for Cscape settings.
