CH.11 MAN0964-01-EN
June 29, 2012 Page 58 of 122
Set %AQ1 = 500 (Hz)
{Start Frequency}
Set %AQ2 = 1000 (Hz) {Run Frequency}
Set %AQ3-4 = 2000000 (Steps) {Accel Count}
Set %AQ5-6 = 2000000 (Steps) {Run Count}
Set %AQ7-8 = 1000000 (Steps) {Decel Count}
Example 3
6,000,000 steps control sequence
The following example starts at 50 Hz and ramps up to 250 Hz during the first 150,000
steps. Then, it runs at 250 Hz for the next 5,500,000 steps. Finally during the last 350,000
steps it slows to a stop.
Set %AQ1 = 50 (Hz)
{Start Frequency}
Set %AQ2 = 250 (Hz) {Run Frequency}
Set %AQ3-4 = 150000 (Steps) {Accel Count}
Set %AQ5-6 = 5500000 (Steps) {Run Count}
Set %AQ7-8 = 350000 (Steps) {Decel Count}
