MAN0964-01-EN CH.12
June 29, 2012 Page 59 of 122
CHAPTER 12: SYSTEM SETTINGS AND ADJUSTMENTS
12.1
System Menu - Overview
The XL4 has a built-in System Menu, which lets the user view System Settings and makes adjustments.
To start the System Menu, press the SYSTEM key (or set %SR3 to 1), which will display the Main Menu.
Then use the ↓ and ↑ (Up Arrow or Down Arrow) keys to select a Main Menu item and press Enter
(Return Arrow) to display the item’s Sub-Menu.
Figure 12.1 – System Menu
CAN Ok? Yes
CAN ID: 253
CAN Baud: 125 KB
MAC ID:
00:00:00:00:00:00
IP: 192.168.0.1
NetM: 0.0.0.0
GatWy: 0.0.0.0
Sub-Menus
Model: XLxxx
OCS Mode: Idle
Scan Rate(mS): 0.0
All Net Use(%): 0.0
Ladder Size: 2
Config Size: 8
Graphics Sz: 8
String Size: 8
Bitmap Size: 8
Text Tbl Size: 8
Font Tbl Size: 8
Protocol Size: 8
SMS File Size: 8
Firmware Rev: 12.26
BIOS Rev: 0.07
FPGA Rev: 2.0
Self-Test: Ok
Logic Error: Ok
User Program: Ok
User Graphics: Ok
W-Dog Trips: 0
Net Errors: 0
Network State: Ok
Network ID: Ok
Dup Net ID: Ok
Clock Error: Ok
I/O System: Ok
Battery: Ok
Slot 1: I/O: Empty
Slot 2: I/O: Empty
Slot 3: I/O: ETN300
Main Menu
Port 1:
(None Loaded)
Port 2:
(None Loaded)
Sub-Menus
Fkeys: Momentary
Sys-Fn enable: Yes
( Use ↓↑ to adjust )
Dflt Pgm Port MJ1-232
MJ2 RS485 Bias No
( Use ↓↑ to adjust )
Time: 10:21:36
Date: 28-Jun-2009
Day: Thursday
( Use ↓↑ to adjust )
( each field )
Saver enable: Yes
Timeout(min): 15
Popup Status: Off
Update Time(mS): 5
Update time sets the
maximum time used by
graphics in the logic
scan.
Media Directory
Media Card Not Present
XL4
Beeper Enable: Yes
( Use ↓↑ to adjust )
Backup/Restore Data
Enable AutoRun
Enable AutoLoad
(ESC to exit)
Clone Unit
Directory Empty
Set Networks
View Status
View Diags
View I/O Slots
View Protocols
Set Fkeys Mode
Set Serial Ports
Set Time/Date
Set Beeper
Set Screen
Removable Media
Fail-Safe System
Clone Unit
(Press ESC to Exit)
