CH.14 MAN0964-01-EN
June 29, 2012 Page 86 of 122
Table 14.2 – %SR Registers
Register Name Description Min Val Max Val
has been performed (Fail Safe)
%SR164.4 Read bit indicating Backup of Register Data has
been performed (Fail Safe)
%SR164.5 Enable AUTORUN (Fail Safe)
%SR164.6 Enable AUTOLOAD (Fail Safe)
%SR164.7 Backup trigger bit
%SR164.8 Clear Backup trigger bit
%SR164.9 MAKE_CLONE trigger bit
%SR164.10 LOAD_CLONE trigger bit
%SR164.11
Status indicating Make Clone Fail (This bit goes
high when Make / Create clone fails)
%SR164.12
Status indicating Load Clone Fail (This bit goes
high when Load clone fails)
%SR165-174 Reserved
%SR175
Removable
Media
Current Removable Media interface status 0 6
%SR176-177
Removable
Media Indicates free space on the Removable Media card
in K bytes.
0 2 31
%SR178-179
Removable
Media
Indicates the total card capacity in K bytes. 0 2 31
%SR180 Reserved - - -
%SR181 ALM_UNACK
Unacknowledged Alarm (high bit indicates what
group #)
%SR182 ALM_ACT Active Alarm (high bit indicates what group #)
%SR183 SYS_BEEP System Beep Enable (0=disabled; 1=enabled)
%SR184 USER_BEEP Software configurable (0=OFF; 1=ON)
%SR185 SCR_SAVER Screen Saver Enabled (0=disabled; 1=enabled)
%SR186 SCR_SA_TM Screen Saver Time in minutes (delay)
%SR187 NET_USE Average Net Usage of all units on the CAN network
%SR188 NET_MIN
Minimum Net Usage of all units on the CAN
network
%SR189 NET_MAX
Maximum Net Usage of all units on the CAN
network
%SR190 NT_TX_AVG Average Net Usage of this unit
%SR191 NT_TX_MIN Minimum Net Usage of this unit
%SR192 NT_TX_MAX Maximum Net Usage of this unit
For additional information on system bits and registers, refer to the on-line help found in Cscape.
