Figure 9-52, Ac97 low power mode timing diagram, Table 9-46 – AMD Geode SC2200 User Manual
Page 416: Ac97 low power mode timing parameters
434
AMD Geode™ SC2200 Processor Data Book
Electrical Specifications
32580B
Figure 9-52. AC97 Low Power Mode Timing Diagram
Table 9-41. AC97 Low Power Mode Timing Parameters
Symbol
Parameter
Min
Typ
Max
Unit
Comments
t
s2_pdown
End of Slot 2 to BIT_CLK,
SDATA_IN low
1.0
µs
SYNC
BIT_CLK
SDATA_OUT
SDATA_IN
Slot 1
Slot 2
Note: BIT_CLK is not to scale
t
s2_pdown
