AMD Geode™ SC2200 Processor Data Book 411
Electrical Specifications 32580B
Figure 9-28. Sustained UltraDMA Data In Burst Timing Diagram
t
DS
t
DH
t
DS
t
DH
t
DH
t
DVH
t
DVS
t
DVH
t
DVS t
DVH
t
2CYC
t
CYC
t
CYC
t
2CYC
IDE_DATA[15:0]
at device
IDE_DATA[15:0]
at host
IDE_IRDY0
(DSTROBE0)
at device
IDE_IRDY0
(DSTROBE0)
at host
Note: IDE_DATA[15:0] and IDE_IRDY[0:1] (DSTROBE[0:1]) signals are shown at both the host and the device to
emphasize that cable settling time and cable propagation delay do not allow the data signals to be considered sta-
ble at the host until a certain amount of time after they are driven by the device.
