374 AMD Geode™ SC2200 Processor Data Book
Electrical Specifications 32580B
9.1.6 Ball Capacitance and Inductance
Table 9-8 gives ball capacitance and inductance values.
Table 9-8. Ball Capacitance and Inductance
Symbol Parameter Min Typ Max Unit Comment
C
IN
Input Pin Capacitance 4 7 pF Note 1
C
IN
Clock Input Capacitance 5 8 12 pF Note 1
C
IO
I/O Pin Capacitance 10 12 pF Note 1
C
O
Output Pin Capacitance 6 8 pF Note 1
L
PIN
Pin Inductance 20 nH Note 2
Note 1. T
A
= 25
°C, f = 1 MHz. All capacitances are not 100% tested.
Note 2. Not 100% tested.
