400 AMD Geode™ SC2200 Processor Data Book
Electrical Specifications 32580B
Figure 9-20. Sub-ISA Write Operation Timing Diagram
t
WRx
t
AWx
Valid Valid
Valid Data
t
WCUx
t
WA
t
DH
A[23:0]/BHE#
TRDE#
D[15:0]
IOCHRDY
t
RDYAx t
RDYH
DOCCS#/ROMCS#
t
IOCSH
IOCS[1:0]#
t
DF
t
DVx
t
IOCSA
IOW#/WR#
MEMW#/DOCW#
IOR#/RD#
MEMR#/DOCR#
t
WTR
Note: x indicates a numeric index for the relevant symbol.
