AMD Geode™ SC2200 Processor Data Book 339
Video Processor Module - Register Summary 32580B
28h-2Bh 32 R/W Miscellaneous Register 00001400h Page 348
2Ch-2Fh 32 R/W PLL2 Clock Select Register 00000000h Page 348
30h-33h 32 --- Reserved 00000000h Page 349
34h-37h 32 RO Reserved 00000000h Page 349
38h-3Bh 32 RO Reserved 00000000h Page 349
3Ch-3Fh 32 R/W Video Downscaler Control Register 00000000h Page 349
40h-43h 32 R/W Video Downscaler Coefficient Register 00000000h Page 349
44h-47h 32 R/W CRC Signature Register xxxxx100h Page 350
48h-4Bh 32 RO Device and Revision Identification 0000015xh Page 350
4Ch-4Fh 32 R/W Video De-Interlacing and Alpha Control Register 00060000h Page 350
50h-53h 32 R/W Cursor Color Key Register 00000000h Page 352
54h-57h 32 R/W Cursor Color Mask Register 00000000h Page 352
58h-5Bh 32 R/W Cursor Color Register 1 00000000h Page 352
5Ch-5Fh 32 R/W Cursor Color Register 2 00000000h Page 352
60h-63h 32 R/W Alpha Window 1 X Position Register 00000000h Page 352
64h-67h 32 R/W Alpha Window 1 Y Position Register 00000000h Page 352
68h-6Bh 32 R/W Alpha Window 1 Color Register 00000000h Page 353
6Ch-6Fh 32 R/W Alpha Window 1 Control Register 00000000h Page 353
70h-73h 32 R/W Alpha Window 2 X Position Register 00000000h Page 353
74h-77h 32 R/W Alpha Window 2 Y Position Register 00000000h Page 353
78h-7Bh 32 R/W Alpha Window 2 Color Register 00000000h Page 354
7Ch-7Fh 32 R/W Alpha Window 2 Control Register 00000000h Page 354
80h-83h 32 R/W Alpha Window 3 X Position Register 00000000h Page 354
84h-87h 32 R/W Alpha Window 3 Y Position Register 00000000h Page 354
88h-8Bh 32 R/W Alpha Window 3 Color Register 00000000h Page 355
8Ch-8Fh 32 R/W Alpha Window 3 Control Register 00000000h Page 355
90h-93h 32 R/W Video Request Register 001B0017h Page 355
94h-97h 32 RO Alpha Watch Register 00000000h Page 355
98h-3FFh --- Reserved --- Page 355
400h-403h 32 R/W Video Processor Display Mode Register 00000000h Page 356
404h-407h 32 --- Reserved 00000000h Page 356
408h-40Bh 32 R/W Video Processor Test Mode Register 00000000h Page 357
40Ch-41Fh --- --- Reserved 00000000h Page 357
420h-423h 32 R/W GenLock Register 00000000h Page 358
424h-427h 32 R/W GenLock Delay Register 00000000h Page 359
428h-43Bh --- --- Reserved --- Page 359
43Ch-43Fh 32 R/W Continuous GenLock Time-out Register 1FFF1FFFh Page 359
Table 7-4. F4BAR0: Video Processor Configuration Registers Summary (Continued)
F4BAR0+
Memory
Offset
Width
(Bits) Type Name
Reset
Value
Reference
(Table 7-7)
