AMD Geode™ SC2200 Processor Data Book

Core Logic Module - X-Bus Expansion Interface - Function 5

32580B

6.4.5.1

X-Bus Expansion Support Registers

F5 Index 10h, Base Address Register 0 (F5BAR0) set the
base address that allows PCI access to additional I/O Con-

trol support registers. Table 6-40 shows the support regis-
ters accessed through F5BAR0.

Index 59h-5Fh

Reserved

Reset Value: xxh

Index 60h-63h

Scratchpad: Usually used for Device Number (R/W)

Reset Value: 00000000h

BIOS writes a value, of the Device number. Expected value: 00002200h.

Index 64h-67h

Scratchpad: Usually used for Configuration Block Address (R/W)

Reset Value: 00000000h

BIOS writes a value, of the Configuration Block Address.

Index 68h-FFh

Reserved

Table 6-39. F5: PCI Header Registers for X-Bus Expansion (Continued)

Bit

Description

Table 6-40. F5BAR0+I/O Offset: X-Bus Expansion Registers

Bit

Description

Offset 00h-03h

I/O Control Register 1 (R/W)

Reset Value: 010C0007h

31:28

Reserved.

27

IO_ENABLE_SIO_IR (Enable Integrated SIO Infrared).

0: Disable.

1: Enable.

26:25

IO_SIOCFG_IN (Integrated SIO Input Configuration). These two bits can be used to disable the integrated SIO totally or
limit/control the base address.

00: Integrated SIO disable.

01: Integrated SIO configuration access disable.

10: Integrated SIO base address 02Eh/02Fh enable.

11: Integrated SIO base address 015Ch/015Dh enable.

24

IO_ENABLE_SIO_DRIVING_ISA_BUS (Enable Integrated SIO ISA Bus Control). Allow the integrated SIO to drive the
internal ISA bus.

0: Disable.

1: Enable. (Default)

23:21

Reserved. Set to 0.

20

IO_USB_SMI_PWM_EN (USB Internal SMI). Route USB-generated SMI to SMI Status Register in F1BAR0+I/O Offset
00h/02h[14].

0: Disable.

1: Enable.

19

IO_USB_SMI_EN (USB SMI Configuration). Allow USB-generated SMIs.

0: Disable.

1: Enable.

If bits 19 and 20 are enabled, the SMI generated by the USB is reported via the Top Level SMI status register at F1BAR0+I/
O Offset 00h/02h[14].

If only bit 19 is enabled, the USB can generate an SMI but there is no status reporting.

18

IO_USB_PCI_EN (USB). Enables USB ports.

0: Disable.

1: Enable.

17:0

Reserved.
