AMD Geode™ SC2200 Processor Data Book 187
Core Logic Module - Register Summary 32580B
Table 6-15. F0BAR0: GPIO Support Registers Summary
F0BAR0+
I/O Offset Width
(Bits) Type Name
Reset
Value
Reference
(Table 6-30)
00h-03h 32 R/W GPDO0 — GPIO Data Out 0 Register FFFFFFFFh Page 233
04h-07h 32 RO GPDI0 — GPIO Data In 0 Register FFFFFFFFh Page 233
08h-0Bh 32 R/W GPIEN0 — GPIO Interrupt Enable 0 Register 00000000h Page 233
0Ch-0Fh 32 R/W1C GPST0 — GPIO Status 0 Register 00000000h Page 233
10h-13h 32 R/W GPDO1 — GPIO Data Out 1 Register FFFFFFFFh Page 233
14h-17h 32 RO GPDI1 — GPIO Data In 1 Register FFFFFFFFh Page 234
18h-1Bh 32 R/W GPIEN1 — GPIO Interrupt Enable 1 Register 00000000h Page 234
1Ch-1Fh 32 R/W1C GPST1 — GPIO Status 1 Register 00000000h Page 234
20h-23h 32 R/W GPIO Signal Configuration Select Register 00000000h Page 235
24h-27h 32 R/W GPIO Signal Configuration Access Register 00000044h Page 235
28h-2Bh 32 R/W GPIO Reset Control Register 00000000h Page 236
Table 6-16. F0BAR1: LPC Support Registers Summary
F0BAR1+
I/O Offset Width
(Bits) Type Name
Reset
Value
Reference
(Table 6-31)
00h-03h 32 R/W SERIRQ_SRC — Serial IRQ Source Register 00000000h Page 237
04h-07h 32 R/W SERIRQ_LVL — Serial IRQ Level Control Register 00000000h Page 238
08h-0Bh 32 R/W SERIRQ_CNT — Serial IRQ Control Register 00000000h Page 240
0Ch-0Fh 32 R/W DRQ_SRC — DRQ Source Register 00000000h Page 240
10h-13h 32 R/W LAD_EN — LPC Address Enable Register 00000000h Page 241
14h-17h 32 R/W LAD_D0 — LPC Address Decode 0 Register 00080020h Page 242
18h-1Bh 32 R/W LAD_D1 — LPC Address Decode 1 Register 00000000h Page 243
1Ch-1Fh 32 R/W LPC_ERR_SMI — LPC Error SMI Register 00000080h Page 243
20h-23h 32 RO LPC_ERR_ADD — LPC Error Address Register 00000000h Page 244
