250

AMD Geode™ SC2200 Processor Data Book

Core Logic Module - SMI Status and ACPI Registers - Function 1

32580B

Offset 06h-07h

Second Level General Traps & Timers Status Register (RC)

Reset Value: 0000h

The bits in this register contain second level of status reporting. Top level status is reported in F1BAR0+I/O Offset 00h/02h[9]. Reading
this register clears the status at both the second and top levels.

A read-only “Mirror” version of this register exists at F1BAR0+I/O Offset 04h. If the value of this register must be read without clearing
the SMI source (and consequently de-asserting SMI), F1BAR0+I/O Offset 04h can be read instead.

15:6

Reserved.

5

PCI/ISA Function Trap. Indicates whether or not an SMI was caused by a trapped PCI/ISA configuration cycle

0: No.1:Yes.

To enable SMI generation for:

— Trapped access to ISA Legacy I/O register space set F0 Index 41h[0] = 1.
— Trapped access to F1 register space set F0 Index 41h[1] = 1.
— Trapped access to F2 register space set F0 Index 41h[2] = 1.
— Trapped access to F3 register space set F0 Index 41h[3] = 1.
— Trapped access to F4 register space set F0 Index 41h[4] = 1.
— Trapped access to F5 register space set F0 Index 41h[5] = 1.

4

SMI Source is Trapped Access to User Defined Device 3 (UDEF3). Indicates whether or not an SMI was caused by a
trapped I/O or memory access to User Defined Device 3 (F0 Index C8h).

0: No.

1: Yes.

To enable SMI generation, set F0 Index 82h[6] = 1.

3

SMI Source is Trapped Access to User Defined Device 2 (UDEF2). Indicates whether or not an SMI was caused by a
trapped I/O or memory access to User Defined Device 2 (F0 Index C4h).

0: No.

1: Yes.

To enable SMI generation, set F0 Index 82h[5] = 1.

2

SMI Source is Trapped Access to User Defined Device 1 (UDEF1). Indicates whether or not an SMI was caused by a
trapped I/O or memory access to User Defined Device 1 (F0 Index C0h).

0: No.

1: Yes.

To enable SMI generation, set F0 Index 82h[4] = 1.

1

SMI Source is Expired General Purpose Timer 2. Indicates whether or not an SMI was caused by the expiration of Gen-
eral Purpose Timer 2 (F0 Index 8Ah).

0: No.

1: Yes.

To enable SMI generation, set F0 Index 83h[1] = 1.

0

SMI Source is Expired General Purpose Timer 1. Indicates whether or not an SMI was caused by the expiration of Gen-
eral Purpose Timer 1 (F0 Index 88h).

0: No.

1: Yes.

To enable SMI generation, set F0 Index 83h[0] = 1.

Offset 08h-09h

SMI Speedup Disable Register (Read to Enable)

Reset Value: 0000h

15:0

SMI Speedup Disable. If bit 1 in the Suspend Configuration Register is set (F0 Index 96h[1] = 1), a read of this register
invokes the SMI handler to re-enable Suspend Modulation.

The data read from this register can be ignored. If the Suspend Modulation feature is disabled, reading this I/O location has
no effect.

Offset 0Ah-1Bh

Reserved

Reset Value: 00h

These addresses should not be written.

Offset 1Ch-1Fh

ACPI Timer Register (RO)

Reset Value: xxxxxxxxh

Note:

This register can also be read at F1BAR1+I/O Offset 1Ch.

31:24

Reserved.

23:0

TMR_VAL. This field returns the running count of the power management timer.

Table 6-33. F1BAR0+I/O Offset: SMI Status Registers (Continued)

Bit

Description
