184

AMD Geode™ SC2200 Processor Data Book

Core Logic Module - Register Summary

32580B

6.3.2

Register Summary

The tables in this subsection summarize the registers of
the Core Logic module. Included in the tables are the regis-
ter’s reset values and page references where the bit for-
mats are found.

Note:

Function 4 (F4) is for Video Processor support
(although accessed through the Core Logic PCI
configuration registers). Refer to Section 7.3.1
"Register Summary" on page 338
for details.

Table 6-14. F0: PCI Header/Bridge Configuration Registers

for GPIO and LPC Support Summary

F0 Index

Width

(Bits)

Type

Name

Reset

Value

Reference

(Table 6-29)

00h-01h

16

RO

Vendor Identification Register

100Bh

Page 198

02h-03h

16

RO

Device Identification Register

0500h

Page 198

04h-05h

16

R/W

PCI Command Register

000Fh

Page 198

06h-07h

16

R/W

PCI Status Register

0280h

Page 199

08h

8

RO

Device Revision ID Register

00h

Page 200

09h-0Bh

24

RO

PCI Class Code Register

060100h

Page 200

0Ch

8

R/W

PCI Cache Line Size Register

00h

Page 200

0Dh

8

R/W

PCI Latency Timer Register

00h

Page 200

0Eh

8

RO

PCI Header Type Register

80h

Page 200

0Fh

8

RO

PCI BIST Register

00h

Page 200

10h-13h

32

R/W

Base Address Register 0 (F0BAR0) — Sets the base address for
the I/O mapped GPIO Runtime and Configuration Registers (sum-
marized in Table 6-15).

00000001h

Page 200

14h-17h

32

R/W

Base Address Register 1 (F0BAR1) — Sets the base address for
the I/O mapped LPC Configuration Registers (summarized in
Table 6-16)

00000001h

Page 200

18h-2Bh

---

---

Reserved

00h

Page 200

2Ch-2Dh

16

RO

Subsystem Vendor ID

100Bh

Page 200

2Eh-2Fh

16

RO

Subsystem ID

0500h

Page 200

30h-3Fh

---

---

Reserved

00h

Page 200

40h

8

R/W

PCI Function Control Register 1

39h

Page 201

41h

8

R/W

PCI Function Control Register 2

00h

Page 201

42h

---

---

Reserved

00h

Page 202

43h

8

R/W

PIT Delayed Transactions Register

02h

Page 202

44h

8

R/W

Reset Control Register

01h

Page 203

45h

---

---

Reserved

00h

Page 203

46h

8

R/W

PCI Functions Enable Register

FEh

Page 203

47h

8

R/W

Miscellaneous Enable Register

00h

Page 204

48h-4Bh

---

---

Reserved

00h

Page 204

4Ch-4Fh

32

R/W

Top of System Memory

FFFFFFFFh

Page 204

50h

8

R/W

PIT Control/ISA CLK Divider

7Bh

Page 204

51h

8

R/W

ISA I/O Recovery Control Register

40h

Page 205

52h

8

R/W

ROM/AT Logic Control Register

98h

Page 205

53h

8

R/W

Alternate CPU Support Register

00h

Page 206

54h-59h

---

---

Reserved

00h

Page 206

5Ah

8

R/W

Decode Control Register 1

01h

Page 206

5Bh

8

R/W

Decode Control Register 2

20h

Page 207

5Ch

8

R/W

PCI Interrupt Steering Register 1

00h

Page 208

5Dh

8

R/W

PCI Interrupt Steering Register 2

00h

Page 208

5Eh-5Fh

---

---

Reserved

00h

Page 208

60h-63h

32

R/W

ACPI Control Register

00000000h

Page 208

64h-6Bh

---

---

Reserved

00h

Page 209
