310 AMD Geode™ SC2200 Processor Data Book
Core Logic Module - ISA Legacy Register Space 32580B
I/O Port 0DEh DMA Write Mask Register Command, Channels 7:4 (W)
Note: Channels 5, 6, and 7 are not supported.
Table 6-43. DMA Channel Control Registers (Continued)
Bit Description
Table 6-44. DMA Page Registers
Bit Description
I/O Port 081h DMA Channel 2 Low Page Register (R/W)
Address bits [23:16] (byte 2).
I/O Port 082h DMA Channel 3 Low Page Register (R/W)
Address bits [23:16] (byte 2).
I/O Port 083h DMA Channel 1 Low Page Register (R/W)
Address bits [23:16] (byte 2).
I/O Port 087h DMA Channel 0 Low Page Register (R/W)
Address bits [23:16] (byte 2).
I/O Port 089h DMA Channel 6 Low Page Register (R/W)
Not supported.
I/O Port 08Ah DMA Channel 7 Low Page Register (R/W)
Not supported.
I/O Port 08Bh DMA Channel 5 Low Page Register (R/W)
Not supported.
I/O Port 08Fh ISA Refresh Low Page Register (R/W)
Refresh address.
I/O Port 481h DMA Channel 2 High Page Register (R/W)
Address bits [31:24] (byte 3).
Note: This register is reset to 00h on any access to Port 081h.
I/O Port 482h DMA Channel 3 High Page Register (R/W)
Address bits [31:24] (byte 3).
Note: This register is reset to 00h on any access to Port 082h.
I/O Port 483h DMA Channel 1 High Page Register (R/W)
Address bits [31:24] (byte 3).
Note: This register is reset to 00h on any access to Port 083h.
I/O Port 487h DMA Channel 0 High Page Register (R/W)
Address bits [31:24] (byte 3).
Note: This register is reset to 00h on any access to Port 087h.
I/O Port 489h DMA Channel 6 High Page Register (R/W)
Not supported.
I/O Port 48Ah DMA Channel 7 High Page Register (R/W)
Not supported.
I/O Port 48Bh DMA Channel 5 High Page Register (R/W)
Not supported.
