AMD Geode™ SC2200 Processor Data Book 377
Electrical Specifications 32580B
9.2.1 IN
AB
DC Characteristics
9.2.2 IN
BTN
DC Characteristics
9.2.3 IN
PCI
DC Characteristics
Note that the buffer type for PCICLK (ball A7) is IN
T
- not IN
PCI
.
Symbol Parameter Min Max Unit Comments
V
IH
Input High Voltage 1.4 V
V
IL
Input Low Voltage -0.5
(Note 1)
0.8 V
I
IL
Input Leakage Current 10 µA V
IN
= V
IO
-10 µA V
IN
= V
SS
V
HIS
Input hysteresis 150 mV
Note 1. Not 100% tested.
Symbol Parameter Min Max Unit Comments
V
IH
Input High Voltage 2.0 V
SB
+0.3
(Note 1)
V
V
IL
Input Low Voltage -0.5
(Note 1)
0.8 V
I
IL
Input Leakage Current 5 µA V
IN
= V
SB
-36 µA V
IN
= V
SS
V
HIS
Input HysteresisNote 1 250 mV
Note 1. Not 100% tested.
Symbol Parameter Min Max Unit Comments
V
IH
Input High Voltage 0.5V
IO
V
IO
+0.3
(Note 1)
Note 1. Not 100% tested.
V
V
IL
Input Low Voltage -0.5
(Note 1)
0.3V
IO
V
V
IPU
Input Pull-up Voltage 0.7V
IO
V Note 2
Note 2. Not 100% tested. This parameter indicates the minimum voltage to which pull-up resistors are calculated in order
to pull a floated network.
l
IL Input Leakage Current +/-10 µA 0 < V
IN
< V
IO,
Note 3, Note 4
Note 3. Input leakage currents include HIZ output leakage for all bidirectional buffers with TRI-STATE outputs.
Note 4. See Exceptions 2 and 3 in Section 9.2.15.1 on page 383.
