AMD Geode™ SC2200 Processor Data Book 269
Core Logic Module - IDE Controller Registers - Function 2 32580B
Index 50h-53h Channel 1 Drive 0 PIO Register (R/W) Reset Value: 00009172h
Channel 1 Drive 0 Programmed I/O Control Register. See F2 Index 40h for bit descriptions.
Index 54h-57h Channel 1 Drive 0 DMA Control Register (R/W) Reset Value: 00077771h
Channel 1 Drive 0 MDMA/UDMA Control Register. See F2 Index 44h for bit descriptions.
Note: The PIO Mode format is selected in F2 Index 44h[31], bit 31 of this register is defined as reserved.
Index 58h-5Bh Channel 1 Drive 1 PIO Register (R/W) Reset Value: 00009172h
Channel 1 Drive 1 Programmed I/O Control Register. See F2 Index 40h for bit descriptions.
Index 5Ch-5Fh Channel 1 Drive 1 DMA Control Register (R/W) Reset Value: 00077771h
Channel 1 Drive 1 MDMA/UDMA Control Register. See F2 Index 44h for bit descriptions.
Note: The PIO Mode format is selected in F2 Index 44h[31], bit 31 of this register is defined as reserved.
Index 60h-FFh Reserved Reset Value: 00h
Table 6-35. F2: PCI Header/Channels 0 and 1 Registers for IDE Controller Configuration (Continued)
Bit Description
