AMD Geode™ SC2200 Processor Data Book 139
SuperI/O Module 32580B
Table 5-41. Bank 3 Register Map
Offset Type Name
00h RO MRID. Module and Revision ID
01h RO SH_LCR. Shadow of LCR
02h RO SH_FCR. Shadow of FIFO Control
03h R/W BSR. Bank Select
04h-07h --- RSVD. Reserved
Table 5-42. Bank 0 Bit Map
Register Bits
Offset Name 7 6 5 4 3 2 1 0
00h RXD RXD[7:0] (Receiver Data Bits)
TXD TXD[7:0] (Transmitter Data Bits)
01h IER 1 RSVD MS_IE LS_IE TXLDL_IE RXHDL_IE
IER 2 RSVD TXEMP_IE RSVD 3 /
DMA_IE 4
MS_IE LS_IE TXLDL_IE RXHDL_IE
02h
EIR
1 FEN[1:0] RSVD RXFT IPR1 IPR0 IPF
EIR 2 RSVD TXEMP_EV RSVD 3 /
DMA_EV 4
MS_EV LS_EV or
TXHLT_EV
TXLDL_EV RXHDL_EV
FCR RXFTH[1:0] TXFTH[1:0] RSVD TXSR RXSR FIFO_EN
03h LCR 5 BKSE SBRK STKP EPS PEN STB WLS[1:0]
BSR
5 BKSE BSR[6:0] (Bank Select)
04h MCR 1 RSVD LOOP ISEN or
DCDLP
RILP RTS DTR
MCR 2 RSVD TX_DFR RSVD RTS DTR
05h LSR ER_INF TXEMP TXRDY BRK FE PE OE RXDA
06h MSR DCD RI DSR CTS DDCD TERI DDSR DCTS
07h SPR 1 Scratch Data
ASCR
2 RSVD
TXUR
4
RXACT
4
RXWDG
4 RSVD
S_OET
4 RSVD RXF_TOUT
1. Non-Extended Mode.
2. Extended Mode.
3. In SP1 only.
4. In SP2 only.
5. When bit 7 of this register is set to 1, bits [6:0] of BSR select the bank, as shown in Table 5-38 on page 139.
