194 AMD Geode™ SC2200 Processor Data Book
Core Logic Module - Register Summary 32580B
Table 6-26. PCIUSB: USB PCI Configuration Register Summary
PCIUSB
Index
Width
(Bits) Type Name Reset Value
Reference
(Table 6-41)
00h-01h 16 RO Vendor Identification 0E11h Page 292
02h-03h 16 RO Device Identification A0F8h Page 292
04h-05h 16 R/W Command Register 00h Page 292
06h-07h 16 R/W Status Register 0280h Page 293
08h 8 RO Device Revision ID 08h Page 293
09h-0Bh 24 RO Class Code 0C0310h Page 293
0Ch 8 R/W Cache Line Size 00h Page 293
0Dh 8 R/W Latency Timer 00h Page 293
0Eh 8 RO Header Type 00h Page 293
0Fh 8 RO BIST Register 00h Page 293
10h-13h 32 R/W Base Address 0 00000000h Page 294
14h-2Bh --- --- Reserved 00h Page 294
2Ch-2Dh 16 RO Subsystem Vendor ID 0E11h Page 294
2Eh-2Fh 16 RO Subsystem ID A0F8h Page 294
30h-3Bh --- --- Reserved 00h Page 294
3Ch 8 R/W Interrupt Line Register 00h Page 294
3Dh 8 R/W Interrupt Pin Register 01h Page 294
3Eh 8 RO Min. Grant Register 00h Page 294
3Fh 8 RO Max. Latency Register 50h Page 294
40h-43h 32 R/W ASIC Test Mode Enable Register 000F0000h Page 294
44h 8 R/W ASIC Operational Mode Enable 00h Page 294
45h-FFh --- --- Reserved 00h Page 294
