AMD Geode™ SC2200 Processor Data Book
263
Core Logic Module - SMI Status and ACPI Registers - Function 1
32580B
8
THT_SMIEN. Allow SMI generation when the THT_EN bit (F1BAR1+I/O Offset 00h[4]) is set.
0: Disable.
1: Enable. (Default)
Top level SMI status is reported at F1BAR0+I/O Offset 00h/02h[2].
Second level SMI status is reported at F1BAR0+I/O Offset 20h/22h[1].
7:4
Reserved. Must be set to 0.
3:0
SCI_IRQ_ROUTE. SCI is routed to:
0000: Disable
0100: IRQ4
1000: IRQ8
1100: IRQ12
0001: IRQ1
0101: IRQ5
1001: IRQ9
1101: IRQ13
0010: Reserved
0010: IRQ6
1010: IRQ10
1110: IRQ14
0011: IRQ3
0011: IRQ7
1011: IRQ11
1111: IRQ15
For more details see Section 6.2.6.3 "Programmable Interrupt Controller" on page 163.
Offset 1Ch-1Fh
PM_TMR — ACPI Timer Register (RO)
Reset Value: xxxxxxxxh
Note:
This register can also be read at F1BAR0+I/O Offset 1Ch.
31:24
Reserved.
23:0
TMR_VAL. (Read Only) This bit field contains the running count of the power management timer.
Offset 20h
PM2_CNT — PM2 Control Register (R/W)
Reset Value: 00h
7:1
Reserved.
0
Arbiter Disable. Disables the PCI arbiter when set by the OS. Used during C3 transition.
0: Arbiter not disabled. (Default)
1: Disable arbiter.
Offset 21h-FFh
Reserved
Reset Value: 00h
The read value for these registers is undefined.
Table 6-34. F1BAR1+I/O Offset: ACPI Support Registers (Continued)
Bit
Description
