378 AMD Geode™ SC2200 Processor Data Book
Electrical Specifications 32580B
9.2.4 IN
STRP
DC Characteristics
9.2.5 IN
T
DC Characteristics
9.2.6 IN
TS
DC Characteristics
9.2.7 IN
TS1
DC Characteristics
Symbol Parameter Min Max Unit Comments
V
IH
Input High Voltage 0.6V
IO
V
IO
+0.3
(Note 1)
V
V
IL
Input Low Voltage 0.3V
IO
V
I
IL
Input Leakage Current 36 µA During Reset: V
IN
= V
IO
−10
µA V
IN
= V
SS
Note 1. Not 100% tested.
Symbol Parameter Min Max Unit Comments
V
IH
Input High Voltage 2.0 V
IO
+0.3
(Note 1)
V
V
IL
Input Low Voltage -0.5
(Note 1)
0.8 V
I
IL
Input Leakage Current 10 µA V
IN
= V
IO
−10
µA V
IN
= V
SS
Note 1. Not 100% tested.
Symbol Parameter Min Max Unit Comments
V
IH
Input High Voltage 2.0 V
IO
+0.3
(Note 1)
V
V
IL
Input Low Voltage -0.5
(Note 1)
0.8 V
I
IL
Input Leakage Current 10 µA V
IN
= V
IO
-10 µA V
IN
= V
SS
V
H
Input Hysteresis 200 mV
Note 1. Not 100% tested.
Symbol Parameter Min Max Unit Comments
V
IH
Input High Voltage 0.5V
IO
V
IO
+0.3
(Note 1)
V
V
IL
Input Low Voltage -0.5
(Note 1)
0.3V
IO
V
I
IL
Input Leakage Current 10 µA V
IN
= V
IO
-10 µA V
IN
= V
SS
V
HIS Input Hysteresis Note 1 200 mV
Note 1. Not 100% tested.
