Table 55 Required configuration files (3DC Multi-Target (Cnt Ac-J Z x Cnt Ac-J Z) configuration) (continued)
Remarks
Description
Item
R-JNL number: Same value as the R-JNL number
between the primary site and remote site 2
Mirror ID: A non-zero value that is different from
the mirror ID of any other Primary
→ Remote 1
and Primary
→ Remote 2 Continuous Access
Journal Z copy pairs
--
Prepare the following route lists by referring to
Route list definition
file and command
device definition
file
•
The route list that is required when all sites are
available
•
Route list used when a failure occurs at a site
(recommended)
This item is not necessary if you use Remote Web
Console to set up logical paths.
A path set for inter-disk controller logical paths
(bidirectional) between the following sites is required:
Path set definition
file
•
Primary site and remote site 1
•
Primary site and remote site 2
•
Remote site 1 and remote site 2
The following table describes the route list required for operation in a 3DC Multi-Target (Cnt Ac-J
Z x Cnt Ac-J Z) configuration.
Table 56 Required route list (3DC Multi-Target (Cnt Ac-J Z x Cnt Ac-J Z) configuration)
Required route list
Remote site 2
state
Remote site 1
state
Primary site
state
Host on which Business
Continuity Manager is
started
Primary
→ Remote 1
Usable
Usable
Usable
Primary host
Primary
→ Remote 2
Primary
→ Remote 1
Unusable
Usable
Usable
Primary
→ Remote 2
Usable
Unusable
Usable
Not required
Unusable
Unusable
Usable
Remote 1
→ Primary
Usable
Usable
Usable
Remote host 1
Remote 1
→ Remote 2
Remote 1
→ Primary
Unusable
Usable
Usable
Remote 1
→ Remote 2
Usable
Usable
Unusable
Not required
Unusable
Usable
Unusable
Remote 2
→ Primary
Usable
Usable
Usable
Remote host 2
Remote 2
→ Remote 1
Remote 2
→ Primary
Usable
Unusable
Usable
Remote 2
→ Remote 1
Usable
Usable
Unusable
Not required
Usable
Unusable
Unusable
Legend:
Usable: The target site can be used.
Unusable: The target site cannot be used because of an error.
Defining a 3DC Multi-Target (Cnt Ac-J Z x Cnt Ac-J Z) configuration 185
