Advanced Opreation
Design Center
89
Design Center
Stage 4 (Sew Setting Stage)
■
Color
Click this button to set the thread color for lines or
regions.
b
Memo:
The Color button appears in the Sewing
Attributes bar when the Region sew button
( ) or Line sew button ( ) has been
turned on.
1.
Click the Color button.
→ A Line Thread Color dialog box similar to
the ones shown below appears.
b
Memo:
To view a list of only the thread colors, clear
the View Details check box.
2.
From the Thread Chart selector, select a
thread color chart or a user thread chart.
c
For details on specifying a user thread
chart or for information on how machines
handle thread colors, refer to “Editing
User Thread Color Lists” on page 190.
3.
From the list of thread colors, click the desired
color.
→ The new color is displayed on the Region
color button or Line color button.
b
Memo:
• The name of the selected color appears at
the bottom of the dialog box.
• For details on the four buttons under the
list, refer to “Special colors” on page 170.
4.
Click Close to set the color and to close the
dialog box.
5. Click the region or outline where you want to
apply the color setting.
c
“Region sew” on page 87, “Line sew” on
page 88 and “Special colors” on page 170
■
Sew type
Use these selectors to set the sew type for lines or
regions.
b
Memo:
The sew type selector appears in the Sewing
Attributes bar when the Region sew button
( ) or Line sew button ( ) has been
turned on.
1.
Click in a sew type selector.
→ The available settings appear.
2.
Click the desired sew type.
→ The new setting appears in the selector.
3.
Click the region or outline where you want to
apply the sew type setting.
c
“Region sew” on page 87 and “Line sew”
on page 88
Specifying sewing attributes
Various sewing attributes for lines and regions can
be set in the Sewing Attribute Setting dialog box.
Toolbar button:
1.
Click in the Toolbar
→ The Sewing Attribute Setting dialog box
appears.
b
Memo:
The region sew attributes appear in the
Sewing Attribute Setting dialog box when
on the Tool Box is selected. The line
sew attributes appear in the Sewing
Attribute Setting dialog box when or
on the Tool Box is selected.
Region sew type Line sew type
Region sew type Line sew type
