Brother PE-DESIGN Ver.6 - Manual (Page 239)

Advanced Opreation Design Database
231
Design Database
Outputting a Catalog of Embroidery
Patterns
Printing
Images of all embroidery patterns in the selected
folder can be printed as a catalog.
1.
In the folder pane, select the folder containing
the embroidery patterns that you want to
catalog.
2. Click File, then Print Setup.
→ A Print Setup dialog box similar to the
one shown below appears.
3.
Under Print Layout, select whether each
pattern is printed on a separate page, 4
patterns are printed on a page or 12 patterns
are printed on a page.
4. Click Print.
→ Images of the selected patterns are print-
ed.
b
Memo:
• If one or more embroidery patterns were
selected in the contents pane, only the
selected patterns are printed.
• The catalog can be printed immediately by
clicking the menu command File – Print.
The embroidery patterns are printed
according to the settings already selected
in the Print Setup dialog box.
Outputting as an HTML file
Instead of being printed, the catalog of embroidery
patterns can be outputted as an HTML file.
1.
In the folder pane, select the folder containing
the embroidery patterns that you want to
catalog.
2. Click File, then Create HTML.
→ A Save As dialog box similar to the one
shown below appears.
3. Select the drive and the folder, and then type
in the name of the HTML file.
4. To add a title at the top of the file and in the title
bar, type the title in the Page Title box.
5.
Under Page Layout, select how the patterns
appear on the page.
6.
Click Save.
→ The HTML file and a folder containing im-
ages of the embroidery patterns are out-
putted to the selected folder.
