Advanced Opreation Layout & Editing
197
Layout & Editing
Saving and Printing
b
Memo:
• Patterns that are either too large or have
too many stitches for the embroidery hoop
size selected with the Hoop size selector,
are displayed with a red crossed-out hoop
( ).
• Patterns created for the optional extra-
large embroidery hoop are displayed with
the symbol.
• Patterns created on a custom-sized
Design Page are displayed with the
symbol.
3. From the Hoop size selector, select the
appropriate size of embroidery hoop.
b
Memo:
• Do not select a hoop size larger than the
embroidery hoop that can be used with
your embroidering machine. Otherwise,
the created original card will not work
correctly with the embroidering machine.
• Make sure to select a hoop size that is the
same or larger than the largest hoop size
of the files you want to write to the card,
otherwise the pattern cannot be written to
a card and “
×” appears.
4. Click , and then select the folder where
the desired pattern file (.pes) is saved. The
available pattern list displays the image of the
embroidery pattern files (.pes).
b
Memo:
If an original card was selected, the patterns
saved on the inserted card are displayed.
5. In the available patterns list, click the pattern
that you want to write onto a card to select it.
b
Memo:
• To deselect a file, simply click it again.
• To switch between the large and small
display size of the embroidery pattern
images shown in the lists, click .
• To display the information (size, number of
stitches, and colors) for the pattern
selected in either list, click . (This
button is available only if a single pattern is
selected.)
• To display a three-dimensional image of
the pattern selected in either list, click
. (This button is available only if a
single pattern is selected.)
• shows the
capacity of the patterns selected in the
selected patterns list.
6. To add the embroidery pattern selected in the
available patterns list to the selected patterns
list, click .
