KROHNE MFC 400 EN - Manual (Page 99)

OPERATION
6
99
MFC 400
www.krohne.com 08/2013 - 4002075802 - MA MFC 400 R02 en
6.5.11 System control
Menu C1.4.1 - Function
This menu makes it possible to switch off certain measuring functions depending on a
programmable process state. When this system state occurs (as set in Fct. C1.4.2), the following
options can be activated:
• Inactive: system control is off
• Flow = 0: Flow set to zero
Menu C1.4.2 - Condition
Selecting the process measurement which activates the system control. Density and
temperature can be selected.
Menu C1.4.3 – Max Limit
Menu C1.4.4 – Min Limit
Setting the limit values to activate system control. Current measuring values outside of this
range activate this function.
.book Page 99 Monday, August 26, 2013 9:05 AM
