6
OPERATION
82
MFC 400
www.krohne.com 08/2013 - 4002075802 - MA MFC 400 R02 en
No. Function Settings / descriptions
C5 I/O HART
C5 I/O HART Selection or display of the 4 dynamic variables (DV) for HART ®
The HART ® current output (terminal A basic I/Os or terminal C modular I/Os)
always has a fixed link to the primary variables (PV). Fixed links of the other
DVs (1-3) are only possible if additional analogue outputs (current and
frequency output) are available; if not, the measurement can be freely
selected from the following list: in Fct. A4.1 "Measurement"
_ stands for 1, 2, 3 or 4
X stands for connection terminals A...D
C5.1 PV is Current output (primary variable)
C5.2 SV is (secondary variable)
C5.3 TV is (tertiary variable)
C5.4 4V is (4th variable)
C5.5 HART Units Changes units of DVs (dynamic variables) in the display
Break: return with ^ key
HART ® display: copies the settings for the display units to the settings for
DVs
Standard: factory settings for DVs
C5._.1 Current Output X Shows the current analogue measured value of the linked current output.
The "measurement" cannot be changed!
C5._.1 Frequency Output X Shows the current analogue measured value of the linked frequency output,
if present. The "measurement" cannot be changed!
C5._.1 HART Dynamic Var. Measurements of the dynamic variables for HART ® .
Select:
Volume Flow / Mass Flow / Diagnosis Value / Flow Velocity /
Totaliser 1 / Totaliser 2 / Totaliser 3 / Operating Hours
