12
Multi-Parameter
Water Quality TROLL
®
TROLL 9500 Operator’s Manual
0095110 rev. 007 01/09
This section provides a quick overview of the initial steps necessary to
get the Multi-Parameter TROLL 9500 ready to take measurements.
You will need—
s
s
s
s
TROLL Com communication cable for deployment
s
QuickCal Kit for the Basic Sensor set (pH, ORP, polarographic
D.O., Conductivity)
PROVIDE POWER
TIP: When the unit ships with a Polarographic Dissolved
Oxygen sensor installed, alkaline batteries are pre-installed
in the device to power the D.O. sensor and keep it
conditioned.
Install batteries in the Multi-Parameter TROLL 9500 as
follows:
1. Unscrew and remove the battery compartment
cover. Slide it up over the cable (if attached).
3 GETTING STARTED
2. Insert two D-size batteries negative side first, positive side up.
3. Replace the battery compartment cover and tighten to compress
the o-ring seals.
Screw the cover down firmly to compress the o-rings and
create a waterproof seal. When properly assembled, the o-
rings will not be vsible.
TIP: The MP TROLL 9500 uses standard off-the-shelf 1.5V
alkaline D-cells.
Alternatively, you may use Saft LSH-20 3.6V lithium D cells.
Use of any other lithium battery will void the product
warranty.
