10
TROLL 9500 Operator’s Manual
0095110 rev. 007 01/09
PRODUCT SPECIFICATIONS
7ETTED
06#
®
, acetal, 316L SS
/PERATING
½#
3TORAGE
Dimensions
47 mm (1.85 in) dia, x 57.7 cm (22.7 in)
long
with RDO adapter
88.4 mm (3.48 in) dia, 57.7 cm (22.7 in)
long
Weight (without cable)
1.4 Kg (3.1 lbs)
Power
Battery type
2 standard alkaline D-cells (1.5 V), or
2 lithium D cells (approx. 3.6 V)
External power input
9-12 VDC (optional)
Data Sampling
-EMORY
1,000,000 individual readings
Fastest linear logging rate 5 seconds (10 seconds with RDO)
Profiling speed
2 seconds
Communications RS485
Computer interface
RS232
Software
Win-Situ
®
4
Desktop/laptop PC with Micro soft
®
Win-
dows
®
2000 SP2 or later (Windows XP,
Windows Vista™), Internet Explorer 5.0
or later, serial com port, CD-ROM drive,
16-64 Mb RAM
Pocket-Situ 4
In-Situ RuggedReader
®
or other sup-
ported handheld PDA running Microsoft
Pocket PC (Windows Mobile
®
) 2003 or
later
Cable
Jacket options
Polyurethane, halogen-free (HF) polyure-
thane, Tefzel
®
Conductors
6 conductors, 24 AWG, polypropylene
insulation
Diameter
6.7 mm (0.265 in)
Connector
Titanium, 18.5 mm (0.73 in) O.D.
Break strength
127 kg (280 lb)
Minimum bend radius
2X cable diameter (13.5 mm, 0.54 in)
Weight
Vented, regular & HF: 14 kg/300 m (32.3
lb/1000 ft)
Non-vented, regular & HF: 16 kg/300 m
(35.6 lb/1000 ft)
Vented Tefzel
®
: 23kg/300m (52 lb/1000 ft)
Factory-Installed Sensors
Pressure/level
Type
Media-isolated piezoresistive silicon
strain gauge
Range
15 psig (0-11 m, 0-35 ft)
30 psia/psig (0-21 m, 0-69 ft)
100 psia/psig (0-70 m, 0-231 ft)
300 psia/psig (0-210 m, 0-692 ft)
Accuracy
better than ± 0.1% FS
Resolution
1
mm
Temperature
Type
Platinum resistance thermometer
2ANGE
½#
!CCURACY
Õ
2ESOLUTION
½#
Barometric pressure
Type
Piezoresistive silicon pressure sensor
Range
0-16.5 psia (854 mm Hg, 33.6 in Hg)
Accuracy
± 0.3% FS (2.54 mm Hg, 0.1 in Hg)
Resolution
0.1 mm Hg, 0.01 in Hg
Turbidity
4YPE
.EPHELOMETER
Range
0-2000
NTU
Accuracy
± 5% or 2 NTU (whichever is greater)
Resolution
0.1
NTU
Turbidity Wiper
Pressure Rating
350 psi (246 m, 807 ft)
/PERATING
½#
Basic Sensors
Conductivity
Type
4-cell conductivity, AC drive
Operating
Range
Low Range sensor 5 μS/cm to 20,000 μS/cm
High Range sensor 150 μS/cm to 112,000 μS/cm
Accuracy
Low Range sensor ± 0.5% or 2 μS/cm (whichever is greater)
when calibrated in region of interest.
High Range sensor ± 0.5% + 2 μS/cm between 150 μS/cm
and 112,000 μS/cm when calibrated in
region of interest. From 70 to 150 μS/cm
& 112,000 to 200,000 μS/cm ± 2% + 4
μS/cm typical
Resolution
Range-dependent
Pressure Rating
350 psi (246 m, 807 ft)
/PERATING
½#
SECTION 2: COMPONENTS & FEATURES
* Base unit = MP TROLL 9500 & factory-installed sensors
